Huntington 3
HTG-3PR Regress Perimeter
HTG-3PR 3″ Aperture Regress Perimeter
Spec Sheets
SPECIFIED LUMEN OUTPUT (SLO) CONFIGURATOR
Please contact factory for Specified Lumen Outputs
DOWNLOAD IES FILES
MEO IES Files
Pro IES Files
Please contact info@extantlighting.com or call (714) 362-8099
DOWNLOAD Revit FILES
Please contact info@extantlighting.com or call (714) 362-8099
Continuous Row Detail
Please contact info@extantlighting.com or call (714) 362-8099
Installation Instructions
Performance Data
Please contact info@extantlighting.com or call (714) 362-8099

Features
- Available in Trimless, Trim Flange, and T-Grid regressed mounting options.
- Multi-depth ceiling options for use in most plenum installations:
- 1.75” Regress: 5.75” – 6.13” Depth (Integral Driver)
- 3” Regress: 7” – 7.38” Depth (Remote Driver)
- Design without compromise: Glare Control, Diffused (Lambertian) or Graze Optics
- Specified Lumen Outputs (SLO) available: 224 lm/ft – 1754 lm/ft
- Minimalistic 3” Aperture
- Individual fixture lengths and seamless continuous runs with no lens breaks up to 300 feet
- Drivers, wiring and serviceability completely accessible from below ceiling with our patent pending toolless “Push to Eject” system
- Toolless Latch System and Quick-Click 5 Wire system allows for simple, quick, and seamless installation
- Proudly crafted in Huntington Beach, CA – USA
