Huntington 3
HTG-3R-LP Recessed LoPro
HTG-3R-LP 3″ Aperture Recessed Linear
EL HTG3 GrayConferenceRoom Recessed 10062020
HTG-3R (Recessed - Ceiling)
HTG-3R (Recessed - Wall)
Extant HTG3 RecessedLoPro
Spec Sheets
SPECIFIED LUMEN OUTPUT (SLO) CONFIGURATOR
DOWNLOAD IES FILES
MEO IES Files
Pro IES Files
Please contact info@extantlighting.com or call (714) 362-8099
DOWNLOAD Revit FILES
Shop Drawings
Installation Instructions
Performance Data
Please contact info@extantlighting.com or call (714) 362-8099
Features
- Low profile depth behind ceiling for use in any plenum installation:
• 1.5” – 1.75” Depth (Remote Driver)
• 2.14” – 2.45” Depth (Integral Driver) - Design without compromise: Specify Batwing, Glare Control, Diffused (Lambertian) or Wall Wash Optics
- Specified Lumen Outputs (SLO) available: 224 lm/ft – 1754 lm/ft
- Sleek 3” Aperture
- Individual fixture lengths and seamless continuous runs with no lens breaks up to 500 feet
- Achieve up to 16 feet on center spacing with 35fc on work surface
- Drivers, wiring and serviceability completely accessible from below ceiling with our patent pending toolless “Push to Eject” System
- Toolless Latch System and Quick-Click 5 Wire system allows for simple, quick, and seamless installation
- Trim Flange, Spackle Flange, 15/16” or 9/16” Grid Lay-in, 15/16” or 9/16” Grid Tegular, Bolt Slot or Armstrong Interlude/USG Identitee
- 4” TechZone™ compatitble for seamless integration
- Proudly crafted in Huntington Beach, CA – USA
- BABA/BABAA Compliant, please contact the factory for additional information and BABA compliance letter. Applies to most standard product offerings.
Patterns
Rectangle
(AxB)
U-Shape
(AxBxC)
L-Shape
(AxB)
